- Voltage: 100V DC (63V AC).
- Temperature Range: -55°C ~ +100°C
- Capacitance Tolerance: ±20%.
- Insulation Resistance @ +20°C: 3 3 x 104M 
- Dielectric: Polyethylene terephthalate film
- Capacitor electrodes: Metal foil
- Encapsulation: Flame-retardent plastic case, UL94 V-O, with epoxy resin seal. Reservoir and decoupling capacitors for high speed digital circuits. Low lnduction and low damping, favorable resonant frequency because of high electrode contact reliability.
- .001MF 100VDC
- (WHD): 7.2 x 6.5 x 2.5mm
