- 20 Turns
- Sealed for board washing and potting in low viscosity material. Leak tested in water at 85°C for one minute.
- Max. Case Size: 20 x 5.0 x 6.0mm (LWH) (Specifications):
- Max. Working Voltage: 200V D.C.
- Resistance Law: Linear
- Resistance Tolerance: 100 Ohm~500K ±10%, Others ±20%
- Wattage Rating: 0.5Watt @ 40°C
- Working Temp. Range: - 55°C ~ + 100°C
- Temp. Coefficient: ± 100 PPM/°C
- Slider Current: 50mA DC
- Dielectric Voltage: 500V RMS
- Insulation Resistance: 1000M min.
- Value: 200K 
