Features:

• Output Voltage: 20V
• Output Current: 3A
• Total output power: 60 Watts
• 2.1mm DC Plug
• 1.8m K9 IEC lead included
• Fully Australian Approved
• Short circuit protection: A short circuit placed on DC output cause no damage or auto-recovery to the power supply.
• Over Volatage protection: When overvoltage occurs on DC output cause no damage or auto-recovery to the power supply

Rating Label

Specifications

Input
• Input voltage rating: 100-240V AC
• Input voltage range: 90-264V AC
• Input frequency rating: 60/50 Hz
• Input frequency range: 63/47 Hz
• AC input current: 1.8 A Max. @100V AC
• AC input power saving: 0.3W Max.@230V AC at no load
• Inrush Current:60 A Max .@100VAC (Cold start)
• 90 A Max .@230VAC (Cold start)
• Leakage current: 0.25mA Max
• Operating temerature: 0°C-40°C
• Storage temperature: -25°C - 85°C
• Operating humidity" 8% to 90%
• Storage humidity: 5% to 95%
• Weight 277.8g

Output
• Output voltage: 20V
• Max. load current: 3A
• Min. load current: 0A
• Output noload voltage: 20V ± 5%
• Output full load voltage: 20V ± 5%
• Output ripple & noise: 300mV max
