Specifications
Unit dimensions 443 x 210 x 470 mm (HWD)
Form factor Mid-Tower
Material 0.6 mm SGCC + Plastic
Motherboard support ATX,Micro-ATX,Mini-ITX
I/O Ports USB3.0 x 2,MIC/AUDIO(HD), Reset, Power
Side Panel Sound Dampening Side Panel
Expansion & Drive Bays
Expansion slots 7
5.25†Bay 1
3.5â€/ 2.5†Bay (Convertible) 2
2.5†2
Air Cooling
Front 2x120mm or 2x140mm (P7 Silent)
Rear 1x120mm
Included 1 x 120mm fan in Front & 1 x 120mm in rear
Liquid Cooling
Front ≤ 280mm limited [up to 55mm thickness with fan]
Rear ≤ 120mm
Clearances
Cable management space ≤ 20mm
Max VGA card length ≤ 390mm
Max CPU height ≤ 165mm
Max PSU Length ≤ 200mm
Miscellaneous
Dust Filtration Front/Bottom
Warranty 2 years
