Product Specifications

• Model: NT1000
• Bluetooth Specification: Version 2.1+EDR
• Effective Scope: 0-10 meters
• Charger lnput Voltage: DC SV
• Frequency Range: 2.4GHz ~ 2.48GHz unlicensed ISM band
• Support Profiles: HSP and HFP Profiles
• Battery: 650mah (Rechargeable Lithium lon Battery)
• Charging Time: Within 3 hours
• MFB Time: Up to 18 hours
• Standby Time: Up to 60 days
• Operating Temperature: 10°C ~ 50°C
• Storing Temperature: -20°C ~ 70°C

Pairing Instructions

• Keep Car Kit and Mobile Phone less than 1 meter apart
• Car Kit must be OFF
• Press and hold MFB button for 6 seconds until the LED flashes red and blue alternatively
• Turn on the Bluetooth on your mobile phone and scan for devices
• Select for &HF66& from the list
• Enter the pre programmed code &0000& and press OK
• When pairing is complete the blue and red LED will stop flashing

In the box

• Bluetooth Handsfree Car Kit
• Mounting Clip
• Car Charger
• USB Cable
