Device Type
Switch - 52 ports - L3 - managed

Enclosure Type
Desktop, rack-mountable - 1U

Ports
48-port 10/100/1000 + 4 combo Gigabit SFP

Power Over Ethernet (PoE)
PoE/PoE+

Performance
Switching capacity: 104 Gbps | Forwarding performance (64-byte packet size): 77.38 Mpps

MAC Address Table Size
16,000 entries

Capacity
4000 active VLANs

Routing Protocol
Static IPv4 routing

Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI

Jumbo Frame Support
9 KB

Authentication Method
SSH, RADIUS, TACACS+

Features
Layer 3 switching, Layer 2 switching, DHCP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, STP support, RSTP support, MSTP support, TFTP support, ACL support, QoS, Jumbo Frames support, MLD snooping

Compliant Standards


RAM
128 MB

Flash Memory
16 MB

Status Indicators
Link activity, port transmission speed, system

Expansion / Connectivity


Interfaces
48 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45 - PoE | 2 x 10BASE-T/100BASE-TX/1000BASE-T - RJ-45 | 1 x console - 9 pin D-Sub (DB-9) - management | 2 x SFP (mini-GBIC)
