Device Type
Switch - 8 ports

Enclosure Type
Desktop

Ports
8 x 10/100/1000

Power Over Ethernet (PoE)
N/A

Performance
Switching capacity : 13.6 Gbps : Forwarding performance (64-byte packet size) : 11.9 Mpps

MAC Address Table Size
8000 entries

Jumbo Frame Support
Yes

Remote Management Protocol
SNMP, RMON, HTTP, TFTP

Encryption Algorithm
MD5

Authentication Method
RADIUS

Features
Layer 2 switching, DHCP support, BOOTP support, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, SNTP support, Spanning Tree Protocol (STP) support, Trivial File Transfer Protocol (TFTP) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, fanless, SNMP, RMON, SNTP, Cisco Discovery Protocol, Auto SmartPorts

Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, 802.3af PoE

RAM
32 MB

Flash Memory
8 MB

Status Indicators
Link activity, port transmission speed, system

Expansion / Connectivity


Interfaces
8 x 10Base-T/100Base-TX/1000Base-T - RJ-45

Power


Power Device
Power supply - external

Voltage Required
100-240V AC/50-60 Hz universal input
