Typical deployment
Enterprise teleworker or service provider managed CPE

Typical number of users
1-10 enterprise teleworkers

Performance positioning
Up to 10 Mbps

WAN


Ethernet
Gigabit Ethernet 10/100/1000

VDSL2/ADSL2+
Multimode VDSL2, ADSL2+, ADSL2 & ADSL1

SHDSL
-

Fiber
-

3G/4G LTE
-

Serial
-

LAN


Ports
5

802.11 wireless
Dual-band concurrent 2.4/5.0 GHz 802.11n Wi-Fi (Q1CY2013)

Voice
-

PoE
-

Software Features


Routing protocols
RIPv1, v2, BGP

IPv6
Yes

Advanced IP services
No

Video/medianet
No

Security


VPN support
Easy VPN, IPsec VPN on highly secure router

ScanSafe
Ready, Secure Router

IPsec tunnels
10

SSL VPN
No

Content filtering
No

Application Experience


Integrated WAN optimization - Cisco WAAS Express
No

Application Visibility and Control (AVC)
No

IOS high-availability features
No

Physical Attributes


Maximum dimensions
1.75 x 9.5 x 9.0 in

Maximum weight
5.5 lb (2.5 kg)

Fanless
Yes

Optional hardened form factor
No
