Device Type
Router – VDSL2 and Ethernet, 4-port switch (integrated)

Enclosure Type
Desktop

Connectivity Technology
Wireless

Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet

Frequency Band
N/A

Performance
VPN throughput: 20 Mbps

Selectable Channels quantity
N/A

Capacity
IPsec VPN tunnels : 5
PPTP VPN tunnels : 5

Network / Transport Protocol
PPTP, Layer 2 Transport Protocol (L2TP), IPsec, Point-to-Point Protocol over Ethernet (PPPoE), DHCP

Routing Protocol
RIP-1, RIP-2, static IP routing

Remote Management Protocol
SNMP 1, SNMP 2, SNMP 3, HTTP, HTTPS

Encryption Algorithm
Triple DES, Secure Hash Algorithm, Message Digest Algorithm (MD5), AES

Authentication method
N/A

Features
Firewall protection, NAT support, Port Address Translation (PAT) support, Network Address Port Translation (NAPT) support, SPI, DoS attack prevention, port mirroring, IPv6 support, VPN passthrough, URL filtering, domain blocking, RSTP support, QoS, DHCP server, port forwarding, port triggering, DHCP client, USB 3G/4G modem broadband support

Compliance standards
IEEE 802.3, IEEE 802.3u, and IEEE 802.3ab

Status Indicators
Port status, system, DMZ, DMZ/Internet, diagnostic

Interfaces
LAN: 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 2 x 10Base-T/100Base-TX/1000Base-T - RJ-45 CLI console

Antenna
Internal

Gain Levels
2 dBi

Power Device
Power adapter - external
