Chipset Intel® Q270
Dimensions 17.7 x 3.42 x 17.47 cm
Drive Bay One 2.5'
Expansion Slot 1 M.2 2230 for optional wireless NIC; 1 M.2 2280 for storage drives
Form Factor Mini
Front I/O 1 USB 3.1 Type-Câ„¢ (charging); 1 USB 3.1 Gen 1; 1 USB 3.1 Gen 1 (charging); 1 Headphone connector; 1 headset connector
Graphics Intel® HD Graphics 630
LAN Intel® I219LM Gigabit Network Connection LOM
Memory 8 GB DDR4-2400 SDRAM (1 x 8 GB)
Operating System Windows 10 Pro 64
Optical Drive No
Power Supply 65 W 89% efficient
Processor Intel® Core™ i7-7700T with Intel HD Graphics 630 (2.9 GHz, up to 3.8 GHz with Intel Turbo Boost, 8 MB cache, 4 cores)
Product Family
Rear I/O 1 security lock slot; 1 external antenna connector; 2 DisplayPortâ„¢; 4 USB 3.1 Gen 1; 1 RJ-45; 1 power connector
Storage Capacity 256 GB PCIe® NVMe™ TLC SSD
Storage Type SSD
Warranty 3-year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.
Weight 1.21 kg
Wireless Intel® 8265 802.11ac (2x2) wireless with Bluetooth® M.2 combo card non-vPro™
