Intel 660P Series M.2 80mm 512GB SSD 3D2 QLC PCIe NVMe 1500R/1000W MB/s 90K/220K IOPS 1.6 Million Hours MTBF Solid State Drive 5yrs Wty

Features: PCIe* Performance at an Affordable Price. Twice the Capacity in Identical Footprints2.

PCIe* Performance at an Affordable Price
Empowered by Intel’s innovative Intel QLC technology, the Intel® SSD 660p offers higher capacities at a lower cost than TLC-based options.2 With PCIe*, the new SSD 660p skips SATA.
2x the Capacity in Identical Footprints1
These client SSDs pack more data than TLC-based storage, allowing up to 2x more capacity in identical footprints. The thin M.2 80mm form factor makes it perfect for notebooks, desktops, and mobile devices that need storage for everyday computing.

Technical Specifications

Essentials
Status Launched
Launch Date Q3'18
Lithography Type 3D2 TLC
Capacity 512 GB

Performance
Sequential Write (up to) 1500 MB/s
Power - Idle 40 mW
Sequential Read (up to) 1000 MB/s
Random Write (8GB Span) (up to) 90000 IOPS
Power - Active 100 mW
Random Read (8GB Span) (up to) 220000 IOPS

Reliability
Shock (Operating and Non-Operating) 1000 G
Mean Time Between Failures (MTBF) 1.6 million hours
Vibration - Operating 2.17 GRMS
Uncorrectable Bit Error Rate (UBER) <1 sector per 10^15 bits read
Warranty Period 5
Endurance Rating (Lifetime Writes) 100 TBW
Vibration - Non-Operating 3.13 GRMS

Package Specifications
Interface PCIe NVMe 3.0 x4
Weight <10 grams
Form Factor M.2 22 x 80mm

Advanced Technologies
Intel® Smart Response Technology Yes
Temperature Monitoring and Logging No
Enhanced Power Loss Data Protection No
Intel® Rapid Start Technology Yes
Intel® Remote Secure Erase No
High Endurance Technology (HET) No
Hardware Encryption AES 256 bit
End-to-End Data Protection Yes
