Memory Specifications
Max Memory Size (dependent on memory type) 1.54 TB
Memory Types DDR4 1600/1866/2133
Max # of Memory Channels 4
Max Memory Bandwidth 68.3 GB/s
Physical Address Extensions 46-bit
ECC Memory Supported ‡ Yes

Graphics Specifications
Processor Graphics ‡ None

Expansion Options
Scalability 2S
PCI Express Revision 3.0
PCI Express Configurations ‡ x4, x8, x16
Max # of PCI Express Lanes 40

Package Specifications
Sockets Supported FCLGA2011-3
Max CPU Configuration 2
TCASE 73°C
Package Size 45mm x 52.5mm
Low Halogen Options Available See MDDS

Advanced Technologies
Intel® Turbo Boost Technology ‡ 2.0
Intel® vPro™ Technology ‡ Yes
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® TSX-NI Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions AVX 2.0
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Intel® Demand Based Switching Yes
Thermal Monitoring Technologies Yes
Intel® Flex Memory Access No
Intel® Identity Protection Technology ‡ No

Intel® Data Protection Technology
Intel® AES New Instructions Yes
Secure Key Yes

Intel® Platform Protection Technology
OS Guard Yes
Trusted Execution Technology ‡ Yes
Execute Disable Bit ‡ Yes
