EDEC standard 1.35V (1.28V ~ 1.45V) and 1.5V (1.425V ~

1.575V) Power Supply

VDDQ = 1.35V (1.28V ~ 1.45V) and 1.5V (1.425V ~ 1.575V)

800MHz fCK for 1600Mb/sec/pin

8 independent internal bank

Programmable CAS Latency: 11, 10, 9, 8, 7, 6

Programmable Additive Latency: 0, CL - 2, or CL - 1 clock

8-bit pre-fetch

Burst Length: 8 (Interleave without any limit, sequential with starting address “000” only), 4 with tCCD = 4 which does not allow seamless read or write [either on the fly using A12 or MRS]

Bi-directional Differential Data Strobe

Internal(self) calibration : Internal self calibration through ZQ pin (RZQ : 240 ohm ± 1%)

On Die Termination using ODT pin

Average Refresh Period 7.8us at lower than TCASE 85°C, 3.9us at 85°C < TCASE < 95°C

Asynchronous Reset

PCB: Height 1.18” (30mm), double sided component
