Level up your TV sound. Enhance your TV, movies and gameswith built-in Alexa voice control, DTS® Virtual:X™virtual 3D surround sound, a wireless subwoofer, and Bluetooth® streaming all in a simple, sleek setup.
“Alexa*, turn the volume up in the lounge room.”
With Alexa voice control integration, all you have to do is ask.
The YAS-209 offers built-in Alexa voice control for easy control of your sound bar, smart home devices, music and more.
Additionally, a Mute feature ensures your privacy when needed by muting Alexa.
Take your home cinema experience to new heights with sound that comes from above as well as all around you.
The YAS-209 features DTS Virtual:X – immersing the audience in exhilarating 3D surround sound from a single barsolution.
A key benefit of having a sound bar is the ability to minimise clutter – eliminating the need for surround speakers and cables throughout a room.
A wireless subwoofer system takes this a step further by offering even greater flexibility in positioning. Experienceexplosive bass while enjoying the versatility of being able to place the subwoofer anywhere in the room.
YAS-209 | ||
---|---|---|
Digital Sound Projector | ||
General | Drivers | Center unit: Front L/R: 4.6 cm (1-3/4”) cone× 4, Tweeter: 2.5 cm (1") dome × 2, Subwoofer: 16 cm (6-1/2”) cone |
Output Power | 200 W (Center unit: 50 W × 2-ch, Subwoofer: 100 W) | |
Power Consumption | Center unit: 25 W, 4.3 W (Voice Control Ready), Subwoofer: 20 W | |
Standby Power Consumption | Center unit: 0.2 W (HDMI control off, network standby off), 1.6 / 1.8 / 1.7 W (HDMI control off, network standby on [Wired / Wi-Fi / Bluetooth®]), 0.6 W (HDMI control on, network standby off), 2.2 W (HDMI control on, network standby on), Subwoofer: 0.8 W | |
Dimensions (W x H x D) | Center unit: 930 × 62 × 109 mm (36-5/8" × 2-1/2" × 4-1/4"), Subwoofer: 191 × 420 × 406 mm (7-1/2" × 16-1/2" × 16") | |
Weight | Center unit: 2.7 kg (6 lbs), Subwoofer: 7.9 kg (17.4 lbs) | |
Input / Output | HDMI | 1 in / 1 out |
Digital Optical | 1 in | |
HDMI | 4K Pass-through | Yes (50 / 60 Hz YCbCr=4:4:4, HDR10, HLG and HDCP2.3) |
3D Pass-through | Yes | |
ARC | Yes | |
CEC | Yes | |
Auto Lip-Sync | Yes | |
Sound Technology | Surround Technology | DTS® Virtual:X™ |
Surround Mode | Music, TV program, Movie, Sports, Game | |
Compressed Music Enhancer | Yes (for Bluetooth) | |
Bass Extended | Yes | |
Audio Formats | Dolby Digital | Yes |
Dolby Pro Logic II | Yes | |
DTS Digital Surround | Yes | |
Connectivity | Wireless Music Streaming | Yes |
Wi-Fi | Yes (2.4 GHz) | |
Bluetooth Version/Profile | Version: Ver 4.2 / Profiles: A2DP, AVRCP / Codecs:SBC, AAC | |
Bluetooth Maximum Communication Range | Approx. 10 m ; 33ft (without obstructions) | |
Wireless Subwoofer | Yes | |
Other Features | App Control | Yes (Sound Bar Controller) |
Front Surround System | ||
Audio Formats | File Format | WAV (PCM format only) / FLAC: up to 192 kHz, ALAC:up to 96 kHz, MP3 / WMA / MPEG-4 AAC: up to 48 kHz |
