Features:
- Specification compliance: Flex ATX v1.0
- Forward converter circuit
- High efficiency and reliability
- Zero minimum load on 3.3V rail
- Low ripple & noise
- Super low noise fan control
- Short circuit protection on all outputs
- Over voltage protection
- Over power protection
- 100% hi-pot test
- 100% burn in, high temperature cycled on/off
- PFC harmonics compliance: EN61000-3-2 +A1 +A2
Dimension:
L150 x W81.5 x H40.6mm
(5.9” x 3.2” x 1.6”)
Connectors:
Main Power (24/20P) x 1
ATX12V (4P) x 1
Peripherals: MOLEX HDD, FDD
