Features:
• Slim design and Easy assembly
• Heat pipe cooling technology
• Fanless Design
• Support 4K Ultra HD
• Industrial Solid Capacitors = High Stability
• 24/7 Nonstop Operation
• External Power button
• VESA Mount Capability

FORM FACTOR
1.3L chassis

PROCESSOR
Support Intel Skylake Core i3/i5/i7, Pemtium, Celeron CPU max. TDP 65W

CHIPSET
Intel H110 Express chipset

MEMORY
2 x 204 pin DDR4 SODIMM slots,16GB per DIMM (Max 32GB)
Dual Channel DDR4 2133 Mhz

VIDEO OUTPUT
HDMI x1 + DisplayPort x1 Support dual display
4K playback (Dual channel memory recommanded)

AUDIO
Realtek ALC662 channel High Definition Audio

ETHERNET
100Mb/s and 1Gb/s operation
Support Wake-On-LAN function
Support Teaming function

STORAGE INTERFACE
SATA 6.0Gb/s interface

ONBOARD CONNECTORS
1x SATA 6 connectors
1x SATA power connector
1x 4pin fan connector
1x Front audio header
1x 1x4 pin USB header
1x D-sub connector
1x Auto power on header
1x External Power on


FRONT PANEL
1x Power-On button
1x Power LED
1x HDD LED
2x USB 2.0 port
2x USB 3.0 port
1x Earphone-Out
1x Microphone-In
1x SD Card reader

BACK PANEL
1x External power on/Clear CMOS header
2x USB 3.0 port
1x HDMI port
1x DisplayPort
1x eSATA+USB2.0 COM port
1x RJ45 Gigabit LAN port
1x PS/2 port
1x DC in
1x Kensington lock
2x Wireless Antenna fixture

DRIVE BAYS
1x 2.5' HDD / SSD bay

DIMENSIONS
190(L) x 165(W) x 43(H) mm

POWER
90W Power Adapter
Input:100- 240V AC
Output: 19V 4.47A DC

EXPANSION SLOT
1x M.2 2260 Type M key socket
1x M.2 2230 Type A,E Key socket
