Features:
• Support up to three independent displays
• Support 4K Ultra HD
• Support HEVC/H.265 high-definition video playback
• 24/7 certified
• Fanless Design
• Support wire and wireless high-speed networks
• Multio I/O includes serial
• Support two M.2 expansion slots
• Support VESA Mount
PROCESSOR
Intel Apollo Lake J3355 CPU Processor
MEMORY
2 x DDR3L SO-DIMM, supports up to 8GB DDR3L 1866 MHz
VIDEO OUTPUT
Intel generation HD Graphic engine
AUDIO
Realtek ALC662
2 channel High Definition Audio
ETHERNET
Intel i211 Gigabit LAN controller
Supports 10/100/1000 Mb/Sec.
Support wake ON LAN (WOL) feature
802.11b/g/n WLAN support (1T1R)
STORAGE INTERFACE
SATA for HDD/SSD
SD card reader
FRONT PANEL
1x Power button
1x Power Led
1x HD Led
1x SD Card reader
2x USB 3.0 port
1x MIC-IN
1x Audio out
BACK PANEL
1x RJ45 Gigabit LAN port
1x HDMI port
1x Display port
4x USB 2.0 ports
1x DC in
1x RS232/RS422/RS485
1x RS232
1x External power on/Clear CMOS header
1x PS/2 Port
1x Connectors for WLAN antenna
DRIVE BAYS
1x 2.5' HDD Max.(9.5mm) / SSD bay
DIMENSIONS
190(L) x 165(W) x 43(H) mm
POWER
Input:100- 240V AC
Output: 19V/2.1A or 12V/3.33A DC
40W 19V Adapter bundled
ACCESSORIES
' Optional ' PVG01 (VGA output)
EXPANSION SLOT
1x M.2 Type M (2280)
1x M.2 Type A/E (2230)
