FORM FACTOR Shuttle AIO form factor
PROCESSOR Intel Kabylake-U Celeron 3865U 15W CPU
MEMORY Support DDR4 2133Mhz memory Max. 32G
VIDEO OUTPUT Intel® HD Graphics
AUDIO Realtek ALC269 two Channel High
2W x 2 Stereo speaker
ETHERNET Intel i211
10MB/s,100MB/s, 1000MB/s
Support Wake-On-LAN、Wake on WLAN function
STORAGE INTERFACE 2.5' SATA3 device bay x 1
BACK PANEL DC in
USB2.0 port x 2
USB3.0 port x 2
HDMI x 1
LAN X 1
MIC in X 1
Headphone X 1
Kensington lock
DIMENSIONS 487 x 321 x 44 (mm)
Dimension drawing
POWER Input:100- 240V AC
Output: 19V/3.42A or 12V/5.42A DC
65W 19V Adapter bundled
ACCESSORIES Quick Guide x 1
Driver DVD x 1
65W Power Adapter x 1
power cord x 1
EXPANSION SLOT (1) M.2 2280 Type B,M key socket
(1) M.2 2230 Type A,E Key socket
LCD Panel 19.5',16:9 Wide Panel ,1600x900,Anti-Glare
Touch screen 19.5 inch Capacitive multi-point touch
Web Cam 2MFHD
Mic Electret Condenser Microphone
Left Side Power-on button
USB2.0 port x 2
SD card reader
Clear CMOS
Wireless LAN Realtek RTL8723AE
Card Reader SD Card Reader
