Performance
# of Cores
10
# of Threads
20
Processor Base Frequency
2.20 GHz
Max Turbo Frequency
3.00 GHz
Cache
13.75 MB L3
# of UPI Links
2
TDP
85 W
Supplemental Information
Embedded Options Available
No
Datasheet
View now
Product Brief
View now
Memory Specifications
Max Memory Size (dependent on memory type)
768 GB
Memory Types
DDR4-2400
Maximum Memory Speed
2400 MHz
Max # of Memory Channels
6
ECC Memory Supported ‡
Yes
Expansion Options
Scalability
2S
PCI Express Revision
3.0
Max # of PCI Express Lanes
48
Package Specifications
Sockets Supported
FCLGA3647
TCASE
78°C
Package Size
76.0mm x 56.5mm
Low Halogen Options Available
See MDDS
